Saw Filter

saw filter list

Part Name2	Center Frequency	Passband Width	Band Width(-3dB)	Insertion Loss	package
SF165M	165	22	25.88	9.3	3.8×3.8
SF243B	243.95	0.22	0.49	2.2	3.0×3.0
SF247B	247.45	0.22	0.49	2.2	3.8×3.8
SF307A	307.075	5.9	12.37	1.5	3.8×3.8
SF308F	308.5	16	18.9	3.2	3.8×3.8
SF315A	315	4		2.8	3.8×3.8
SF315M1	315		0.63	2.6	3.0×3.0
SF315.12M1	315.12		0.63	3.3	3.0×3.0
SF328F	328	16	19.4	3.5	3.8×3.8
SF340C	340	8	15.2	2.65	3.8×3.8
SF344AN	344	3		4	3.8×3.8
SF344A		6	14.44	1.6	3.8×3.8
SF350A		4	13.71	2.8	3.8×3.8
SF354.5A		7	12.14	2.3	3.8×3.8
SF364.5A		7	12.5	1.9	3.8×3.8
SF369A		4	8.75	3	3.8×3.8
SF374E			22	9	3.8×3.8
SF375.5C		11	15.3	1.8	3.8×3.8
SF380C1		10	15.6	1.8	3.8×3.8
SF383A		6	13.4	2.5	3.8×3.8
SF387A		6	13.44	2	3.8×3.8
SF384C	384	4	13	1.6	3.8×3.8
SF390G	390	20		9	3.8×3.8
SF393A	390.5	5	12.93	3.2	3.8×3.8
SF398A	398	4	9.1	2.5	3.8×3.8
SF403C	403	8	16.7	2.5	3.8×3.8
SF410A	410	6	10.26	2.5	3.8×3.8
SF418A	418	4	10.7	3.2	3.8×3.8
SF422A	422	6	10.6	3	3.8×3.8
SF426A	426	6	10.6	2.8	3.8×3.8
SF428W	428	12	17.46	1.8	3.8×3.8
SF430A	430	7	10.7	2	3.8×3.8
SF433.92A1	433.92	1.71	6.93	2.5	3.0×3.0
SF433C	433	10	14.67	2.68	3.8×3.8
SF433M	433.92		0.6	3	3.8×3.8
SF433M1	433.92		0.72	2.4	3.0×3.0
SF434A	433.92	6	11.88	2.5	3.8×3.8
SF434B	434	6	8.96	2.2	3.8×3.8
SF440A	440	4	15.7	2.3	3.8×3.8
SF446A	446	4	10.9	3.2	3.8×3.8
SF446B	446	6	10.6	2	3.8×3.8
SF454A	454	4	12	3	3.8×3.8
SF455A1	455	10	13.5	2.2	3.8×3.8
SF458A	458	6	11.1	3.2	3.8×3.8
SF458C	458	10	17	3.2	3.8×3.8
SF460E	460	20	27.7	2.6	3.8×3.8
SF465A	465	6	11.6	3	3.8×3.8
SF465A1	465	10	18.8	2.5	3.8×3.8
SF465B	465	6	9.4	2.2	3.8×3.8
SF465C	465	10	18.4	3.3	3.8×3.8
SF467A	467	6	11.8	2.2	3.8×3.8
SF470A	470	6		3	3.8×3.8
SF474B	474	6		3	3.8×3.8
SF475C	475	10		2	3.8×3.8
SF477A	477	6	11.5	3	3.8×3.8
SF477C	477	8	20.9	2.8	3.8×3.8
SF480-1	480	2	17.2	18.7	3.8×3.8
SF480A	480	6	12.3	3	3.8×3.8
SF480C	480	6	19.6	3.2	3.8×3.8
SF482A1	482	8	19.2	1.8	3.8×3.8
SF485C	485	10	18.8	2	3.8×3.8
SF495C	495	10	18.8	2	3.0×3.0
SF498A	498	5	19.8	2	3.8×3.8
SF546A	546	8	21.7	1.8	3.8×3.8
SF618A	618	8	22.8	2.2	3.8×3.8
SF618A	618	8	22.8	2.2	3.8×3.8
SF626A	626	8	24	1.8	3.8×3.8
SF666A	666	8	25.2	2	3.8×3.8
SF674A	674	8	25.1	2	3.8×3.8
SF682A	682	8	25.6	1.8	3.8×3.8
SF707C	707	18	26.7	4.1	3.8×3.8
SF714A	714	18	27	2.2	3.8×3.8
SF722A	722	18	25.5	1.8	3.8×3.8
SF736C	736	12	30	3.5	3.8×3.8
SF738A	738	8	27.3	1.8	3.8×3.8
SF744E	744.5	8	26.6	3.1	3.8×3.8
SF746A	746	8	18	2.6	3.8×3.8
SF746A2	746	8	27.5	2.3	3.8×3.8
SF754A	754	8	27.9	2	3.8×3.8
SF760E	760.5	19	26.1	1.5	3.8×3.8
SF764A	794.2375	8	14	2.5	3.8×3.8
SF765E	765.5	20	28.8	3.3	3.8×3.8
SF767AN	767	3	9.7	3.3	3.0×3.0
SF770C	770	12	33.4	3.3	3.8×3.8
SF770A	770	8	28.4	2.5	3.8×3.8
SF775E	775.5	18		2.5	3.8×3.8
SF778A	778	8	28.2	2.5	3.8×3.8
SF782C	782	12	28.1	2.2	3.8×3.8
SF786A	786	8	28.9	1.6	3.8×3.8
SF787E	787	22	28	2.5	3.0×3.0
SF794A	794	8	28.3	2.1	3.8×3.8
SF798AT	798	22		3	3.8×3.8
SF802A1	802	8	28.9	2.1	3.8×3.8
SF806C	806	12	35	3.3	3.0×3.0
SF812E	812	18	30	1.7	3.8×3.8
SF815E	815.5	20	55.8	1.7	3.0×3.0
SF820AN	820.5	3	9.5	3	3.0×3.0
SF821A	821	4	12.2	3.5	3.0×3.0
SF826E	826.75	19	29.5	2.5	3.8×3.8
SF827A	827.5	15	32.8	2.1	3.0×3.0
SF834E	834	30	39.6	2.5	3.0×3.0
SF836E	836.5	25	31.8	2	3.0×3.0
SF836E1	836.5	25	39.5	2.5	3.0×3.0
SF841E	841.25	19	29.3	2.5	3.8×3.8
SF847E	847	30	40.2	2.5	3.0×3.0
SF860C	860.5	19	36.2	3.5	3.0×3.0
SF860C1	860.5	19	33.4	2	3.0×3.0
SF860E	860	30	40.7	2.5	3.8×3.8
SF864AN	864	2	12.6	3.8	3.0×3.0
SF864AN1	864	3	10.3	3.2	3.0×3.0
SF865C	865	10	19.1	3.5	3.8×3.8
SF866A	866	4	11.6	4	3.0×3.0
SF868.3A1	868.3	7	13.8	3.1	3.8×3.8
SF868.35A	868.35	4	13.7	3.6	3.0×3.0
SF869A1	869	7	13.8	3.2	3.0×3.0
SF869AN	869	2	12.2	4	3.0×3.0
SF870A	869.85	4	13.1	3.8	3.8×3.8
SF872A	872.5	15	32.7	2.2	3.0×3.0
SF879E	879	30	41	2.5	3.0×3.0
SF881E	881.5	25	32.5	2.2	3.0×3.0
SF886A	886	4	16.2	3.2	3.0×3.0
SF897E3	897	24	30	2.5	3.0×3.0
SF897E	897.5	35	41.6	2.2	3.0×3.0
SF900E	900	25	34.6	2	3.0×3.0
SF902E	902.5	25	34.6	2	3.0×3.0
SF903A1	903.75	7.5	17.7	3.2	3.0×3.0
SF912AN1	912.5	3	11.1	3	3.0×3.0
SF915A1	915	7		2.2	3.0×3.0
SF915AN	915	2	13.4	3.2	3.0×3.0
SF915AT	915	26	39.5	2.8	3.0×3.0
SF915C	915	26	38.5	3.5	3.0×3.0
SF915C1	915	26	33	1.5	3.0×3.0
SF916AN1	916	3	10.8	3	3.0×3.0
SF921A2	921	6	14.5	3.2	3.8×3.8
SF922A1	922.5	7	21.8	3.2	3.0×3.0
SF922A	922.5	7	26	3.5	3.0×3.0
SF922.5A	922.5	6	15.2	2.5	3.0×3.0
SF924AN	924.5	3	11	3	3.0×3.0
SF929AN	929	3	11	3	3.0×3.0
SF930A	930	4	16.3	2.5	3.8×3.8
SF931A	931	4	16.4	2.5	3.8×3.8
SF942E	942.5	35	44	2.5	3.0×3.0
SF942E3	942	24	35	2.5	3.0×3.0
SF945E	945	25	37.6	2.2	3.0×3.0
SF947E	947.5	25	37.6	2.2	3.0×3.0
SF948A	948.75	7.5	20	3.8	3.0×3.0
SF959A	959	2	15	2.8	3.8×3.8
SF972C	972	20	41	3.5	3.8×3.8
SF1575A	1575.42	2.4	34	1.5	3.0×3.0
SHDF2441E	2441.8	8.5		2.2	3.0×3.0
